SAMSUNG 970 EVO PLUS M.2 2280 2TB PCIe Gen 3.0 x4, NVMe 1.3 V-NAND 3-bit MLC Internal Solid State Drive (SSD) MZ-V7S2T0B/AM

$144.99

SAMSUNG 970 EVO PLUS M.2 2280 2TB PCIe Gen 3.0 x4, NVMe 1.3 V-NAND 3-bit MLC Internal Solid State Drive (SSD) MZ-V7S2T0B/AM

Interface
PCIe Gen 3.0 x4, NVMe 1.3
Read/Write Speeds
3,500/3,300 MB/s

1 in stock

SKU: SSD-SMS-M2-2TB-002 Categories: , , Tags: , , , , , , , , ,

Description

    • INNOVATIVE V-NAND TECHNOLOGY: Powered by Samsung V-NAND Technology, the 970 EVO Plus SSD’s NVMe interface (PCIe Gen 3.0 x4 NVMe 1.3) offers enhanced bandwidth, low latency, and power efficiency ideal for tech enthusiasts, high end gamers, and 4K & 3D content designers
    • BREAKTHROUGH READ WRITE SPEEDS: Sequential read and write performance levels of up to 3,500 MB/s and 3,300 MB/s, respectively; Random Read (4KB, QD32): Up to 620,000 IOPS Random Read
    • PERFORMANCE OPTIMIZATION AND DATA SECURITY: Seamless cloning and file transfers with Samsung Magician Software, the ideal SSD management solution for performance optimization and data security with automatic firmware updates
    • SUPERIOR HEAT DISSIPATION: Samsung’s Nickel-coated controller and Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to minimize performance drops
    • 1200 TBW (Terabytes Written)

Features

Always Evolving SSD

The ultimate in performance, upgraded. Faster than the 970 EVO, the 970 EVO Plus is powered by the latest V-NAND technology and firmware optimization. It maximizes the potential of NVMe bandwidth for unbeatable computing. Comes in capacities of up to 2TB, with reliability of up to 1,200 TBW. 1

Level up Performance

The 970 EVO Plus reaches sequential read/write speeds up to 3,500/3,300 MB/s, up to 53%* faster than the 970 EVO. Powered by the latest V-NAND technology—which brings greater NAND performance and higher power efficiency—along with optimized firmware, a proven in-house controller, and Intelligent TurboWrite boost speed. 2 3 4

Design Flexibility

The next advancement in NVMe SSDs. The 970 EVO Plus fits up to 2TB onto the compact M.2 (2280) form factor, greatly expanding storage capacity and saving space for other components. Samsung’s innovative technology empowers you with the capacity to do more and accomplish more.

Exceptional Endurance

The new standard in sustainable performance. Get up to 1,200 TBW* with a 5-year limited warranty for lasting performance. The 970 EVO Plus provides exceptional endurance powered by the latest V-NAND technology and Samsung’s reputation for quality. 5 6 7

Unparalleled Reliability

Achieve a new level of drive confidence. Samsung’s advanced nickel-coated controller and heat spreader on the 970 EVO Plus enable superior heat dissipation. The Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to minimize performance drops.

Samsung Magician

Advanced drive management made simple. The Samsung Magician software will help you keep an eye on your drive. A suite of user-friendly tools helps keep your drive up to date, monitor drive health and speed, and even boost performance.

Specification
Product Type
NVMe SSD
Storage Type
Internal
Interface
PCIe Gen 3.0 x4, NVMe 1.3
Read/Write Speeds
3,500/3,300 MB/s
Usage Application
Client PCs
Series
970 EVO Plus
Consumer
Yes
Capacity
2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Sequential Read Speed
Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
Sequential Write Speed
Up to 3,300 MB/s * Performance may vary based on system hardware & configuration
Random Read Speed
Random Read (4KB, QD32): Up to 620,000 IOPS; Random Read (4KB, QD1): Up to 19,000 IOPS * Performance may vary based on system hardware & configuration
Random Write Speed
Random Write (4KB, QD32): Up to 560,000 IOPS; Random Write (4KB, QD1): Up to 62,000 IOPS * Performance may vary based on system hardware & configuration
Controller
In-house
NAND Flash
Samsung V-NAND 3-bit MLC
Cache Memory
Samsung 2GB Low Power DDR4 SDRAM
Trim Support
Supported
AES Encryption
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
Security
AES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive (IEEE1667)
S.M.A.R.T. Support
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
WWN Support
Not supported
Device Sleep Mode Support
Yes
Internal Storage
Samsung V-NAND 3-bit MLC
Temperature proof
Yes
NVMe
Yes
Gaming SSDs
Yes
Average Power Consumption (system level)
*Average: 6 W*Maximum: 9 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
Voltage
3.3 V ± 5 % Allowable voltage
Reliability (MTBF)
1.5 Million Hours Reliability (MTBF)
Operating Temperature
0 – 70 ℃ Operating Temperature
Shock
1,500 G & 0.5 ms (Half sine)
Product
M.2 (2280)
Product
3.16″ x 0.87″ x 0.09″
Product
0.3 oz.
Management SW
Magician Software for SSD management
Product
5-Year Limited Warranty or: 1200 TBW Limited Warranty
  1. 1 GB=1,000,000,000 bytes by IDEMA. A certain portion of capacity may be used for system file and maintenance use, so the actual capacity may differ from what is indicated on the product label.
  2. 2 Performances may vary depending on SSD’s firmware version and system hardware & configuration. Performance measurements based on IOmeter 1.1.0. The write performances were measured with Intelligent TurboWrite technology being activated. The sequential write performances after Intelligent TurboWrite region are: 400 MB/s(250GB), 900 MB/s(500GB), 1,700 MB/s(1TB) and 1,750 MB/s(2TB).
  3. 3 Test system configuration: Intel Core i7-7700K CPU @4.2GHz, DDR4 2400MHz 32GB, OS-Windows 10 Built 10240, Chipset–ASUS PRIME Z270-A.
  4. 4 Up to 53 percent performance increase for sequential write speed for 250GB version
  5. 5 TBW: Terabytes Written
  6. 6 Warrantied TBW for 970 EVO Plus: 150 TBW for 250GB model, 300 TBW for 500GB model, 600 TBW for 1TB model, 1,200 TBW for 2TB model.
  7. 7 -years or TBW, whichever comes first. For more information on the warranty, please find the enclosed warranty statement in the package.
